product model

HDR-60-5

HDR-60- 12

HDR-60-24

HDR-60-48

DC output voltage and current

5V10A

12V5A

24V2 .5A

48V1 .25A

Ripples and noise

80mV p-p

120mV p-p

150mVp-p

200mVp-p

voltage accuracy

±2%

±1%

±1%

±1%

Load stability

±1%

±1%

±1%

±1%

productiveness

87%

88%

90%

91%

Adjustable range of DC voltage

±10%

±10%

±10%

±10%

input voltage range

90- 264VAC

dash current

Cold start current 30A/ 110V~60/230V

overload protection

105% --130% cut output, reset: automatic recovery

excess voltage protection

115%/145% protection mode: turn off the output voltage and restart the output

Start, rise and hold time

500ms  30ms / 230VAC        1000ms 30ms / 115VAC

resistance to pressure

I/ P-O/ P :3KvAC ,     l/P-FG : 1 .5KvAC , O/ P- FG:0 .5KvAC ,

Isolation resistance

I/ P-O/ P,  I/ P- FG,   O/ P- FG:500VDC/ 100MΩ

Working temperature and humidity

- 10℃~ +60℃，20% ~90% RH

safety standards

Comply with GB4943,

EMC standard

Complies with GB9254, NECCLASS82-264 2/CPS

weight

0 .36Kg
