product model

HDR-150-12

HDR-150-24

HDR-150-48

output

12V ,0~ 12.5 A

24V ,0~ 6.3A

48V ,0~3.2 A

D-value

±2 %

± 1 %

± 1 %

scope

80mV

80mV

100mV

productiveness

80%

84%

85%

input voltage range

88~ 132VAC/ 176~264VA C

input currenton

3.3A/ 115V 2A/230V

dash current

Cold start current 30A / 115V 60A / 230V

Leakage current

<3 .5 mA/240VAC

Adjustable range of DC voltage

Rated output voltage ±10%

overload protection

105 ~ 135% cut output, automatic recovery

excess voltage protection

125 ~ 142% cut output, automatic recovery

Start, rise, hold time

500ms   70ms   30ms

resistance to pressure

I/ P-O/ P :3KvAC 1  minute

Working temperature and humidity

- 10℃~ +60℃

Weight/packaging

0 .8 kg , 20pcs/16kg/1 . 1 CUFT
