model

NDR-75- 12

NDR-75-24

NDR-75-48

output

12V ,0~6.3 A

24V ,0~3.2 A

48V ,0~ 1.6 A

D-value

±2 %

± 1 %

± 1 %

scope

100mV

150mV

240mV

productiveness

76%

80%

81%

input voltage range

85~264VAC/ 120~370VDC

input currenton

1 .8A/ 115V 0 .90A/230V

dash current

Cold start current 30A / 115V 60A / 230V

Adjustable range of DC voltage

Rated output voltage ±10%

overload protection

Cut output 105~ 150%, automatic recovery

excess voltage protection

121~ 142% cut output, automatic recovery

Start, rise, hold time

1000ms   60ms   50ms

resistance to pressure

I/ P-O/ P :3KvAC 1 minute  I/ P- F/G : 1 .5KvAC 1 minute

Working temperature and humidity

- 10℃~ +50℃,20%~90% RH

Weight/packaging

0 .6 kg , 20pcs/12kg/1 . 1 CUFT
