600W high-power switching power supply

The input range for communication can be selected through a switch
Capable of withstanding a 300vac surge input for 5 seconds
Idle power consumption<0.75W
The working temperature can reach up to 70 ℃
Protection type: short circuit/overload/overvoltage
Natural air cooling
High efficiency, long lifespan, and high reliability
Power start LED indicator light
100% full load aging test

详细信息

model	SNK-600-5	SNK-600-12	SNK-600-24	SNK-600-36	SNK-600-48
DC output voltage and current	5V80A	12V/50A	24V25A	36V 16 .7A	48V12 .5A
Ripples and noise	75mVp-p	75mVp-p	100mVp-p	100mVp-p	120mVp-p
Line stability	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%
Load stability	±0.5%	±0.5%	±0.5%	±0.5%	±0.5%
productiveness	80%	84%	85%	84%	87%
Adjustable range of DC voltage	±10%	±10%	±10%	±10%	±10%
input voltage range	176-264VAC 47-63HZ-250-370VDC
dash current	Cold start current 60A/230V
overload protection	Cut output of 105% ~ 130%, and automatically recover
excess voltage protection	115%/135% protection mode: turn off the output voltage and restart the output
Start, rise and hold time	200ms 50ms 20ms
resistance to pressure	Between input and output: 1.5KvAC between input and housing: 1.5Kv between output and housing: 0.5Kv for one minute
Isolation resistance	Input and output: input and housing: output and housing: 500VDC/100MΩ
Working temperature and humidity	- 10℃~ +60℃ ，20%~90%RH
safety standards	Comply with GB4943, UL60950, EN60950
EMC standard	It meets GB9254, EN55022 grade B
weight	1 .8Kg
