2000W high-power switching power supply

110VAC or 220VAC input
Capable of withstanding a 300vac surge input for 5 seconds
Idle power consumption<0.75W
The working temperature can reach up to 70 ℃
Protection type: short circuit/overload/overvoltage
Natural air cooling
High efficiency, long lifespan, and high reliability
Power start LED indicator light
100% full load aging test

详细信息

model	SNK-2000-12	SNK-2000-24	SNK-2000-36	SNK-2000- 48
DC output voltage	12V	24V	36V	1-48V
Output voltage tolerance	± 1%	± 1%	± 1%	± 1%
rated output current	120A	83A	55A	41A
Output current range	0~120A	0~83A	0~55A	0~41A
Ripple and noise (note 3)	150mVp-p	150mVp-p	200mVp-p	200mVp-p
Line entry stability (Note 4)	± 0.5 %	± 0.5 %	± 0.5 %	± 0.5 %
Load stability (note 5)	± 0.5 %	± 0.5 %	± 0.5 %	± 0.5 %
DC output power	1500W	1600W	1800W	2000W
productiveness	84%	84%	85%	85.5 %
Adjustable range of DC voltage	±10%	±10%	±10%	± 10%
input voltage range	190~240VAC/47~ 63Hz
input currenton	7A/230V
dash current	50A/230V
leakage current	< 3.5mA/240VAC
overload protection	105%~ 150% type: Cut off output reset: automatic recovery
excess voltage protection	115%/135% protection mode: turn off the output voltage and restart the output
High temperature protection	≥70℃ Cut output
