product model |
LRS-75-5 |
LRS-75- 12 |
LRS-75-24 |
LRS-75-48 |
|
DC output voltage and current |
5V15A |
12V6.3A |
24V3.2A |
48V1.5A |
|
Ripples and noise |
79mVp-p |
120mVp-p |
160mVp-p |
200mVp-p |
|
Line stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
|
Load stability |
±1% |
±0.5% |
±0.5% |
±0.5% |
|
productiveness |
81% |
85% |
88% |
89% |
|
Adjustable range of DC voltage |
±10% |
±10% |
±10% |
±10% |
|
input voltage range |
85-264VAC 120-360VAC |
|||
|
dash current |
45A/230V |
|||
|
overload protection |
105% --130% cut output, reset: automatic recovery |
|||
|
excess voltage protection |
Protection mode: turn off the output voltage and restart the output |
|||
|
Start, rise and hold time |
1000ms 30ms /230VAC 2000ms 30ms /115VAC |
|||
|
resistance to pressure |
Input and output: 2.5KvAC, input and enclosure: 1.5KvAC, output and enclosure: 0.5KvAC for one minute |
|||
|
Isolation resistance |
Input and output, input and housing, output and housing: 500VDC/100M Ω |
|||
|
Working temperature and humidity |
- 10℃~ +60℃ ，20%~90%RH |
|||
|
safety standards |
Comply with GB4943, |
|||
|
EMC standard |
It meets GB9254 and EN55022 grade A |
|||
|
weight |
0.22Kg |
|||
