LRS-100W Switching Power Supply

The input range for communication can be selected through a switch
Capable of withstanding a 300vac surge input for 5 seconds
Idle power consumption<0.3W
The working temperature can reach up to 70 ℃
Protection type: short circuit/overload/overvoltage
Natural air cooling
High efficiency, long lifespan, and high reliability
Power start LED indicator light
100% full load aging test

详细信息

product model	LRS- 100-5	LRS- 100-12	LRS- 100-24	LRS- 100-48
DC output voltage and current	5V18A	12V8.3A	24V4 .1A	48V2A
Ripples and noise	100mVp-p	120mVp-p	150mVp-p	200mVp-p
Line stability	±0.5%	±0.5%	±0.5%	±0.5%
Load stability	±1%	±0.5%	±0.5%	±0.5%
productiveness	85%	88%	90%	91%
Adjustable range of DC voltage	±10%	±10%	±10%	±10%
input voltage range	85-264VAC 120-360VAC
dash current	50A/230V
overload protection	105% --130% cut output, reset: automatic recovery
excess voltage protection	115%/145% protection mode: turn off the output voltage and restart the output
Start, rise and hold time	500ms 55ms / 230VAC 500ms 30ms / 115VAC
resistance to pressure	Input/output: 4KvAC, input and housing: 2KvAC, output and housing: 1.25KvAC for one minute
Isolation resistance	Input and output, input and housing, output and housing: 500VDC/100M Ω
Working temperature and humidity	- 10℃~ +60℃，20% ~90% RH
safety standards	Comply with GB4943,
EMC standard	It meets GB9254, EN55022 grade A
weight	0 .34Kg
