The input range for communication can be selected through a switch
Capable of withstanding a 300vac surge input for 5 seconds
Idle power consumption<0.3W
The working temperature can reach up to 70 ℃
Protection type: short circuit/overload/overvoltage
Natural air cooling
High efficiency, long lifespan, and high reliability
Power start LED indicator light
100% full load aging test
High efficiency, long lifespan, and high reliability
Power start LED indicator light
100% full load aging test
|
product model |
LRS-350- 12 |
LRS-350-24 |
LRS-350-36 |
LRS-350-48 |
|
DC output voltage and current |
12V29A |
24V14.5A |
36V9 .7A |
48V7 .3A |
|
Ripples and noise |
150mVp-p |
150mVp-p |
150mVp-p |
200mVp-p |
|
Line stability |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
|
Load stability |
±1% |
±0.5% |
±0.5% |
±0.5% |
|
productiveness |
87% |
88% |
90% |
91% |
|
Adjustable range of DC voltage |
±10% |
±10% |
±10% |
±10% |
|
input voltage range |
90-132VAC 180-264VAC is selected by the switch |
|||
|
dash current |
Cold start current 60A/ 110V~230V |
|||
|
overload protection |
Cut off output by 105% --130%. Reset: automatic recovery |
|||
|
excess voltage protection |
115%/145% protection mode: turn off the output voltage and restart the output |
|||
|
Start, rise and hold time |
1300ms 50ms / 230VAC |
|||
|
resistance to pressure |
I/ P-O/ P :3KvAC , l/P-FG :2KvAC , O/ P- FG:0 .5KvAC , |
|||
|
Isolation resistance |
I/ P-O/ P, I/ P- FG, O/ P- FG:500VDC/ 100MΩ |
|||
|
Working temperature and humidity |
- 10℃~ +60℃，20% ~90% RH |
|||
|
safety standards |
Comply with GB4943, |
|||
|
EMC standard |
It meets GB9254, EN55022 grade A |
|||
|
weight |
0 .76Kg |
|||
